Turnkey PCB Assembly

NextPCB can give you
competitive prices on high quality,
turnkey PCB manufacture and assembly.

High Quality Assembly

NextPCB uses AOI & X-Ray testing to guarantee the quality of assembled PCBs

Small Production Runs

NextPCB is capable of small as well as large production runs for PCB assembly, starting from as few as 1 piece.

Global Delivery

On-time shipping with DHL
NEXTPCB Turnkey PCB Assembly Service
  • PCB Prototype & Manufacturing
  • PCB Assembly
  • Components Sourcing
  • Functional Testing
  • IC Programming
NextPCB has been a specialist in PCB Prototype and PCB Manufacturing for 15 years. In order to offer the best service and competitive price to our customers, we dedicate a PCB prototype engineer and a PCB manufacturing engineer dedicated to each PCB fabrication. We also hold IATF, ISO, UL, RoHS, and REACH certifications ensuring the PCB quality. Our capabilities include:
  • ●PCBs up to 32 layers
  • ●Min.Trace/Space 3.5mil(3.5mil)
  • ●Choose from Fr-4, Arlon, Polyamide substrate materials
  • ●Quantities from 1-1000+
  • ●PCB Dimensions up to 500*600mm
  • ●Board Thicknesses from 0.6mm - 2.5mm
  • ●Dimensional Tolerance of ±0.2mm
  • ●Min. hole size of 0.2mm
  • ●Outer Copper Weights of 35um/70um/105um
  • ●Inner Copper Weight
NextPCB offers quick turnkey PCB assembly service, which can meet your needs from prototype quantities as well as small-volume to big-volume production. We deal with the whole process including: Sourcing all the components, PCB manufacturing, PCB assembly, testing, and final shipment. We have our own PCB Assembly manufacturer with 27 production lines to provide professional PCBA service and competitive price for our customers.
  • ●Surface Mount (SMT) Assembly
  • ●Ball-Grid-Array (BGA) Assembly
  • ●Mixed technology (SMT & Thru-hole)
  • ●Through-Hole Assembly
  • ●Mixed Assembly
  • ●Reflow Soldering
  • ●Wave Soldering
  • ●Pick & Place Assembly
  • ●SMT Solder Paste Printing
We are capable of sourcing any required components in order to offer our customers a comprehensive PCB Assembly service. As we have been providing circuit assembly service for more than 15 years, NextPCB has already established cooperation with a number of world-famous component distributors including Digi-Key, Mouser Electronics, Arrow Electronics, Avnet, etc. this makes it possible for you to get high-quality components at low price.

Component Sourcing Types:

  • ●Full turnkey (All sourced by NextPCB)
  • ●Partial turnkey
  • ●Kitted/Consigned

SMT Parts Presentation:

  • ●Cut tape
  • ●Partial reel
  • ●Reel
  • ●Tube
  • ●Tray
  • ●Laser-cut stainless steel

Component Types:

  • ●BGA 0.25mm pitch
  • ●Passive components as small as 01005 (0402) package
  • ●Fine-pitch components as small as 0.38mm pitch
  • ●Cable & Wire
  • ●Bulk
NextPCB uses multiple methods to test the circuit board projects as the final step of assembly services. We do our best to make sure that you can get what you pay for!
  • ●Automated Optical Inspection(AOI)
  • ●In-Circuit Testing (ICT)
  • ●Functional Testing(FCT)
  • ●X-Ray testing
  • ●Multiple stages of Visual Inspection

NextPCB could offer quick turnaround IC programming services, which will transfer a computer program into an integrated computer circuit.

We support lots of different package types (DIP, SDIP, SOP, MSOP, QSOP, SSOP, TSOP, TSSOP, PLCC, QFP, QFN, MLP, MLF, BGA, CSP, SOT and so on.). You can contact with your sales representative or support@nextpcb.com to help you.

We appreciate it a lot that the Intellectual Property(IP) contains the hard-working and wisdom of PCB engineers, so we prepare a Non-Disclosure Agreement (NDA) document to sign for each business cooperation. We also have a qualified programming management system.

PCB Assembly Capabilities:

Assembly Types

Surface Mount (SMT) Assembly

Ball-Grid-Array (BGA) Assembly

Mixed technology (SMT & Thru-hole)

Through-Hole Assembly

Mixed Assembly

Kit Assembly 		SMT Parts Presentation:

Cut tape

Partial reel

Reel

Tube

Tray

Laser-cut stainless steel

 Components Sourcing

Full turnkey (All components sourced by NextPCB)

Partial turnkey

Kitted/Consigned
Component Types

BGA 0.25mm pitch with X-ray testing

Passive components as small as 01005 (0402) package

Fine-pitch components as small as 0.38mm pitch

Hard metric connectors

Cable & Wire

Bulk

 Quality Inspection

Visual Inspection

AOI Checking

BGA placement – X-RAY checking

In-Circuit Test

Functional test

 Others

Assembly Time:From 24 hours to 7days once all parts are ready

Max. Board Size
500mm X 400mm

MOQ:1 pieces
Board Types Rigid PCBs, Flexible PCB, metal
core PCBs,
Rigid-Flex PCBs 		Solder Types Lead-Free (RoHS compliant) ———— ————

Products Portfolio & PCB Assembly Service

  • Rigid PCB Assembly

  • Flexible PCB Assembly

  • Rigil-flex PCB Assembly

  • Cable Assembly

  • Pick&Place machine

  • Reflow Oven

  • SMT Lines

  • Wave Soldering Line

How to place a SMT/ components order

If you have any questions, please don’t hesitate to contact us by email for one-on-one sales assistance: support@nextpcb.com

  • Online Quote
  • Login/Sign up
  • Upload files
  • Verify Files
  • Payment
  • Fabrication
  • Delivery
  • Confirm Receipt
  • Feedback
